Series 1 – Peroxide-cure silicone with high tear resistance
Series 1 is a peroxide-cured VMQ silicone formulation designed for demanding industrial applications that require high tear strength, sound mechanical behaviour and stable performance in continuous service.
Shore A hardness40 – 70
Temperature range-60 °C / 200 °C
Density (g/cm³)1.12 – 1.19
Tensile strength (MPa)6.0 – 8.0
Elongation at break (%)500 – 600
Tear strength (kN/m)26.0 – 40.0
Curing systemPeroxide
Processing methodExtrusion and Moulding
Base colourNatural / Transparent
Available coloursVarious colours from the RAL chart
Applications
- Inflatable gaskets, tubes, profiles and moulded silicone parts.
Certifications and technical standards
- FDA 21 CFR §177.2600
- BfR IX and XV
- CE 1935/2004 (food contact depending on formulation)
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 2 – Peroxide-cure silicone for general and food-grade use
Series 2 is a peroxide-cured silicone compound designed for versatile processing by extrusion and moulding.
Shore A hardness10 – 90
Temperature range-60 °C / 200 °C
Peak temperature315 °C
Density (g/cm³)1.07 – 1.23
Tensile strength (MPa)3.5 – 9.5
Elongation at break (%)125 – 950
Tear strength (kN/m)10.0 – 23.0
Curing systemPeroxide
Processing methodExtrusion and Moulding
Base colourNatural / Transparent
Available coloursRAL colours on request
Applications
- Tubes (Øint 0.5–145 mm), profiles (cords, square, rectangular), moulded parts and varied industrial applications.
Certifications and technical standards
- FDA 21 CFR 177.2600
- BfR IX and XV
- CE 1935/2004 (Food contact)
- ISO 10993 (medical grade depending on formulation)
- USP Class VI
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 4 – Peroxide-cure silicone with low compression set and oil resistance
Series 4 is a peroxide-cured VMQ silicone formulation developed specifically for applications requiring excellent elastic recovery after compression (low compression set) and good resistance to oil contact.
Shore A hardness40 – 80
Temperature range-60 °C / 200 °C
Density (g/cm³)1.11 – 1.40
Tensile strength (MPa)6.0 – 7.5
Elongation at break (%)100 – 350
Tear strength (kN/m)10.0 – 15.0
Curing systemPeroxide
Processing methodExtrusion and Moulding
Base colourTranslucent beige / Opaque beige
Available coloursRAL colours on request
Applications
- Moulded parts or profiles subjected to repeated stress, O-rings, damping systems.
Certifications and technical standards
- FDA 21 CFR §177.2600
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- NF ISO 815
- ISO 3302 (M2/E1/L2)
Series 5 – PVMQ silicone (Phenyl) for extreme sub-zero temperatures (-110°C)
Series 5 is a phenyl silicone blend (PVMQ base) catalysed with peroxide, designed specifically to provide exceptional cold resistance.
Shore A hardness50
Temperature range-110 °C / 200 °C
Density (g/cm³)1.21
Tensile strength (MPa)8.0 – 8.0
Elongation at break (%)550 – 550
Tear strength (kN/m)28.0 – 28.0
Catalysis typePeroxide
Processing methodExtrusion and moulding
Base colourNatural / Transparent
Available coloursRAL colours on request
Applications
- Profiles, moulded parts, cryogenic equipment, parts subjected to vibration.
Certifications and technical standards
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 7 – Peroxide silicone with high tear and abrasion resistance
Series 7 is a peroxide-cured silicone compound designed to deliver superior mechanical properties, specifically high tear strength and good abrasion resistance.
Shore A hardness60 – 70
Temperature range-60 °C / 230 °C
Density (g/cm³)1.19
Tensile strength (MPa)6.9 – 8.0
Elongation at break (%)400 – 400
Tear strength (kN/m)30.0 – 35.0
Curing systemPeroxide
Processing methodExtrusion and Moulding
Base colourNatural / Transparent
Available coloursRAL colours on request
Applications
- Inflatable gaskets, profiles, moulded parts and industrial bellows.
Certifications and technical standards
- FDA 21 CFR §177.2600
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 9 – Peroxide-cure silicone with excellent thermal resistance (300°C)
Series 9 is a peroxide-cured silicone compound formulated specifically to deliver excellent thermal stability.
Shore A hardness40 – 68
Temperature range-60 °C / 300 °C
Peak temperature315 °C
Density (g/cm³)1.11 – 1.20
Tensile strength (MPa)6.0 – 8.0
Elongation at break (%)300 – 400
Tear strength (kN/m)12.0 – 17.0
Curing systemPeroxide
Processing methodExtrusion and Moulding
Base colourNatural / Transparent
Available coloursRAL colours on request
Applications
- Profiles, industrial oven equipment, moulded parts and extreme thermal applications.
Certifications and technical standards
- FDA 21 CFR §177.2600
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 10 – High-tear platinum-cure silicone for medical and food-grade applications
Series 10 is a platinum-catalysed silicone blend designed to deliver exceptionally high tear strength.
Shore A hardness40 – 80
Temperature range-60 °C / 200 °C
Density (g/cm³)1.12 – 1.24
Tensile strength (MPa)7.0 – 9.0
Elongation at break (%)320 – 760
Tear strength (kN/m)33.0 – 55.0
Catalysis typePlatinum
Processing methodExtrusion and moulding
Base colourNatural / Transparent
Available coloursRAL colours on request
Applications
- Inflatable seals, tubes, profiles and moulded parts for industrial, medical and food-contact applications.
Certifications and technical standards
- FDA 21 CFR §177.2600
- BfR IX and XV
- CE 1935/2004
- ISO 10993 (depending on formulation)
- USP Class VI
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 11 – Peroxide-cure electroconductive silicone
Series 11 is a peroxide-catalysed silicone blend with electroconductive properties.
Shore A hardness50 – 70
Temperature range-50 °C / 210 °C
Density (g/cm³)1.11 – 1.16
Tensile strength (MPa)5.0 – 5.0
Elongation at break (%)100 – 250
Tear strength (kN/m)5.0 – 10.0
Catalysis typePeroxide
Processing methodMoulding (extrusion subject to evaluation)
Base colourBlack
Available coloursBlack only
Applications
- Wiring equipment, connectors, moulded parts and components with electrical conductivity.
Certifications and technical standards
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/L2)
Series 12 – Platinum-cure silicone with strong mechanical properties and versatility
Series 12 is a platinum-cured silicone compound processable by extrusion and moulding, recognised for its strong mechanical properties.
Shore A hardness20 – 90
Temperature range-60 °C / 200 °C
Peak temperature315 °C
Density (g/cm³)1.11 – 1.20
Tensile strength (MPa)6.0 – 9.0
Elongation at break (%)100 – 1000
Tear strength (kN/m)17.0 – 30.0
Curing systemPlatinum
Processing methodExtrusion and Moulding
Base colourNatural / Transparent
Available coloursRAL colours on request
Applications
- Tubes (Øint 0.5–145 mm), profiles (cords, square, rectangular), moulded parts and industrial or medical applications.
Certifications and technical standards
- FDA 21 CFR §177.2600
- BfR IX and XV
- CE 1935/2004
- ISO 10993 (depending on formulation)
- USP Class VI
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 13 – Fluorosilicone (FVMQ) with high resistance to oils and solvents
Series 13 is a fluorosilicone blend (FVMQ base) catalysed with peroxide, designed specifically to provide exceptional resistance to mineral oils, fuels and organic solvents.
Shore A hardness40 – 70
Temperature range-60 °C / 170 °C
Density (g/cm³)1.40 – 1.46
Tensile strength (MPa)6.0 – 7.0
Elongation at break (%)160 – 400
Tear strength (kN/m)10.0 – 21.0
Catalysis typePeroxide
Processing methodExtrusion and moulding
Base colourNatural / Transparent
Available coloursRAL colours on request
Applications
- Profiles, moulded parts and special components for environments with oils or solvents.
Certifications and technical standards
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 14 – Enhanced peroxide silicone for steam and fluid resistance
Series 14 is a peroxide-cured silicone compound formulated specifically to improve resistance to water steam, coolant fluids and oils.
Shore A hardness60 – 70
Temperature range-60 °C / 200 °C
Density (g/cm³)1.16 – 1.20
Tensile strength (MPa)8.0 – 8.0
Elongation at break (%)300 – 360
Tear strength (kN/m)15.0 – 18.0
Curing systemPeroxide
Processing methodExtrusion and Moulding
Base colourNatural / RAL colours
Available coloursRAL colours on request
Applications
- Autoclave gaskets, parts in contact with steam or coolants.
Certifications and technical standards
- FDA 21 CFR §177.2600
- BfR IX and XV
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 16 – Fire-retardant self-extinguishing peroxide silicone (EN 45545-2)
Series 16 is a peroxide-catalysed silicone blend, processable by extrusion and moulding, designed specifically to provide excellent fire resistance and self-extinguishing properties.
Shore A hardness30 – 85
Temperature range-60 °C / 200 °C
Density (g/cm³)1.09 – 1.26
Tensile strength (MPa)5.0 – 9.0
Elongation at break (%)380 – 850
Tear strength (kN/m)17.0 – 25.0
Oxygen index (LOI)32.7
Smoke density (Ds max)84.7
ITC / Hazard Level0.06
Railway hazard levelHL1, HL2, HL3
Catalysis typePeroxide
Processing methodExtrusion and moulding
Base colourBlack / Blue-black (RAL 9017 / RAL 5004)
Available coloursBlack (RAL 9017), Blue-black (RAL 5004)
Applications
- Railway applications (seals, profiles, gaskets, thermal protections, insulation panels).
Certifications and technical standards
- EN 45545-2 R22/R23 HL1-HL2-HL3
- RoHS compliant
- REACH compliant
- NF EN 45545-2:2020
- EN ISO 4589-2 (O₂ Index 32.7%)
- EN ISO 5659-2 (Ds max 84.7)
- EN 17084 (ITC PNL 0.06)
Series 17 – Platinum-cure short-term implantable silicone (< 29 days)
Series 17 is a platinum-catalysed silicone blend, designed specifically for medical applications requiring short-term implantation (less than 29 days according to NUSIL data).
Shore A hardness25 – 80
Temperature range-60 °C / 200 °C
Density (g/cm³)1.11 – 1.20
Tensile strength (MPa)7.9 – 10.8
Elongation at break (%)700 – 1200
Tear strength (kN/m)33.5 – 46.7
Catalysis typePlatinum
Processing methodExtrusion and moulding
Base colourTranslucent
Applications
- Tubing, tubing with radiopaque lines, profiles, moulded parts and O-rings for medical applications.
Certifications and technical standards
- USP Class VI
- ISO 10993 (depending on formulation)
- RoHS compliant
- REACH compliant
Series 20 – Peroxide silicone with high tear and high thermal resistance (270°C)
Series 20 is a peroxide-cured silicone compound that combines two critical properties: excellent tear strength and high thermal stability.
Shore A hardness45 – 70
Temperature range-60 °C / 270 °C
Density (g/cm³)1.12 – 1.20
Tensile strength (MPa)7.0 – 8.0
Elongation at break (%)400 – 550
Tear strength (kN/m)30.0 – 36.0
Curing systemPeroxide
Processing methodExtrusion and Moulding
Base colourNatural / Transparent
Applications
- Inflatable gaskets, profiles, high-temperature moulded parts.
Certifications and technical standards
- FDA 21 CFR §177.2600
- RoHS compliant
- REACH compliant
Series 22 – Peroxide silicone resistant to steam and aromatic oils
Series 22 is a peroxide-cured silicone compound processable by extrusion and moulding.
Shore A hardness40 – 80
Temperature range-60 °C / 200 °C
Density (g/cm³)1.11 – 1.36
Tensile strength (MPa)6.4 – 7.9
Elongation at break (%)130 – 390
Tear strength (kN/m)9.5 – 14.0
Curing systemPeroxide
Processing methodExtrusion and Moulding
Base colourRAL1013 Translucent
Applications
- Autoclave gaskets, moulded parts, O-rings.
Certifications and technical standards
- FDA 21 CFR §177.2600
- RoHS compliant
- REACH compliant
Series 30 – Platinum-cure silicone for peristaltic pumps and extrusion
Series 30 is a platinum-catalysed silicone blend, formulated exclusively for the extrusion process.
Shore A hardness50 – 65
Temperature range-60 °C / 180 °C
Density (g/cm³)1.14 – 1.17
Tensile strength (MPa)8.0 – 8.8
Elongation at break (%)400 – 500
Tear strength (kN/m)17.0 – 39.0
Catalysis typePlatinum
Processing methodExtrusion
Base colourTranslucent beige / Opaque beige
Available coloursRAL colours on request
Applications
- Silicone tubing, peristaltic pumps, extruded profiles and industrial or medical applications.
Certifications and technical standards
- FDA
- USP Class VI
- ISO 10993 (depending on formulation)
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (E1/L2)
