Series 2 – Peroxide-cure silicone for general and food-grade use
Series 2 is a peroxide-cured silicone compound designed for versatile processing by extrusion and moulding. It stands out for an exceptionally wide hardness range (10 to 90 Shore A) and the option of food-contact compliance depending on the formulation.
Peroxide-cured silicone compound. Provides excellent thermal stability and the option of food-contact or medical-grade use depending on the formulation.
Shore A hardness10 – 90
Temperature range-60 °C / 200 °C
Peak temperature315 °C
Density (g/cm³)1.07 – 1.23
Tensile strength (MPa)3.5 – 9.5
Elongation at break (%)125 – 950
Tear strength (kN/m)10.0 – 23.0
Curing systemPeroxide
Processing methodExtrusion and Moulding
Base colourNatural / Transparent
Available coloursRAL colours on request
Applications
- Tubes (Øint 0.5–145 mm), profiles (cords, square, rectangular), moulded parts and varied industrial applications.
Certifications and technical standards
- FDA 21 CFR 177.2600
- BfR IX and XV
- CE 1935/2004 (Food contact)
- ISO 10993 (medical grade depending on formulation)
- USP Class VI
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 12 – Platinum-cure silicone with strong mechanical properties and versatility
Series 12 is a platinum-cured silicone compound processable by extrusion and moulding, recognised for its strong mechanical properties. It offers a very wide hardness range (10 to 90 Shore A) and food-contact compliance. A notable feature is that suction tubes manufactured with the EQ1260T grade are validated for integration into medical devices requiring CE marking.
Platinum-cured silicone with excellent mechanical properties and broad hardness availability. Processable by extrusion and moulding, compatible with food contact and medical applications (depending on formulation).
Shore A hardness20 – 90
Temperature range-60 °C / 200 °C
Peak temperature315 °C
Density (g/cm³)1.11 – 1.20
Tensile strength (MPa)6.0 – 9.0
Elongation at break (%)100 – 1000
Tear strength (kN/m)17.0 – 30.0
Curing systemPlatinum
Processing methodExtrusion and Moulding
Base colourNatural / Transparent
Available coloursRAL colours on request
Applications
- Tubes (Øint 0.5–145 mm), profiles (cords, square, rectangular), moulded parts and industrial or medical applications.
Certifications and technical standards
- FDA 21 CFR §177.2600
- BfR IX and XV
- CE 1935/2004
- ISO 10993 (depending on formulation)
- USP Class VI
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 10 – High-tear platinum-cure silicone for medical and food-grade applications
Series 10 is a platinum-catalysed silicone blend designed to deliver exceptionally high tear strength. It can be processed by extrusion and moulding. Platinum curing gives it superior purity (no peroxide by-products), making it ideal for medical applications (USP Class VI, ISO 10993) and food contact, while also ensuring high-performance mechanical properties.
High-purity technical silicone catalysed with platinum, processable by extrusion and moulding. It offers very good tear strength, excellent mechanical properties and food and medical compatibility depending on the formulation. It has a thermal range from -60 °C to +200 °C and is available in a wide range of hardnesses (40–80 ShA).
Shore A hardness40 – 80
Temperature range-60 °C / 200 °C
Density (g/cm³)1.12 – 1.24
Tensile strength (MPa)7.0 – 9.0
Elongation at break (%)320 – 760
Tear strength (kN/m)33.0 – 55.0
Catalysis typePlatinum
Processing methodExtrusion and moulding
Base colourNatural / Transparent
Available coloursRAL colours on request
Applications
- Inflatable seals, tubes, profiles and moulded parts for industrial, medical and food-contact applications.
Certifications and technical standards
- FDA 21 CFR §177.2600
- BfR IX and XV
- CE 1935/2004
- ISO 10993 (depending on formulation)
- USP Class VI
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 14 – Enhanced peroxide silicone for steam and fluid resistance
Series 14 is a peroxide-cured silicone compound formulated specifically to improve resistance to water steam, coolant fluids and oils. It is processable by extrusion and moulding. It delivers good compression set properties, making it ideal for autoclave gaskets and applications in hot, humid environments where other silicones may degrade faster.
Shore A hardness60 – 70
Temperature range-60 °C / 200 °C
Density (g/cm³)1.16 – 1.20
Tensile strength (MPa)8.0 – 8.0
Elongation at break (%)300 – 360
Tear strength (kN/m)15.0 – 18.0
Curing systemPeroxide
Processing methodExtrusion and Moulding
Base colourNatural / RAL colours
Available coloursRAL colours on request
Applications
- Autoclave gaskets, parts in contact with steam or coolants.
Certifications and technical standards
- FDA 21 CFR §177.2600
- BfR IX and XV
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 22 – Peroxide silicone resistant to steam and aromatic oils
Series 22 is a peroxide-cured silicone compound processable by extrusion and moulding. It is characterised by good stability against water steam and resistance to certain aromatic oils (at low dosages). Unlike other standard series, its base colour is RAL 1013 (Translucent). It is a technical solution suitable for autoclave gaskets, moulded parts and O-rings exposed to mixed conditions of temperature and specific fluids.
Peroxide-cured silicone with good stability against steam and aromatic oils in low concentration. Processable by extrusion and moulding.
Shore A hardness40 – 80
Temperature range-60 °C / 200 °C
Density (g/cm³)1.11 – 1.36
Tensile strength (MPa)6.4 – 7.9
Elongation at break (%)130 – 390
Tear strength (kN/m)9.5 – 14.0
Curing systemPeroxide
Processing methodExtrusion and Moulding
Base colourRAL1013 Translucent
Applications
- Autoclave gaskets, moulded parts, O-rings.
Certifications and technical standards
- FDA 21 CFR §177.2600
- RoHS compliant
- REACH compliant
Series 9 – Peroxide-cure silicone with excellent thermal resistance (300°C)
Series 9 is a peroxide-cured silicone compound formulated specifically to deliver excellent thermal stability. It is processable by extrusion and moulding. Its main feature is the ability to operate across a wide temperature range, withstanding from -60°C to +300°C in continuous service, with short peaks up to 315°C. It is the ideal material for oven equipment and industrial applications with high thermal demands.
Peroxide-cured silicone with excellent thermal resistance, suitable for continuous use up to +300 °C and short peaks of +315 °C. Offers strong mechanical properties and stability across a wide temperature range (-60 °C to +300 °C). Recommended for oven applications, profiles and moulded parts subjected to high temperatures.
Shore A hardness40 – 68
Temperature range-60 °C / 300 °C
Peak temperature315 °C
Density (g/cm³)1.11 – 1.20
Tensile strength (MPa)6.0 – 8.0
Elongation at break (%)300 – 400
Tear strength (kN/m)12.0 – 17.0
Curing systemPeroxide
Processing methodExtrusion and Moulding
Base colourNatural / Transparent
Available coloursRAL colours on request
Applications
- Profiles, industrial oven equipment, moulded parts and extreme thermal applications.
Certifications and technical standards
- FDA 21 CFR §177.2600
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 16 – Fire-retardant self-extinguishing peroxide silicone (EN 45545-2) PEQ
Series 16 is a peroxide-catalysed silicone blend, processable by extrusion and moulding, designed specifically to provide excellent fire resistance and self-extinguishing properties. It complies with railway standard EN 45545-2 version 2020 (Requirements R22 and R23, levels HL1, HL2 and HL3), which makes it the ideal choice for sealing gaskets, profiles and parts in environments where fire safety is critical.
Peroxide-catalysed technical silicone with fire-retardant formulation optimised for the railway sector. It complies with R22/R23 requirements of EN 45545-2:2020 (HL1, HL2, HL3). Processable by extrusion, it offers high thermal resistance, mechanical stability and low emission of smoke and toxic gases.
Shore A hardness30 – 85
Temperature range-60 °C / 200 °C
Density (g/cm³)1.09 – 1.26
Tensile strength (MPa)5.0 – 9.0
Elongation at break (%)380 – 850
Tear strength (kN/m)17.0 – 25.0
Oxygen index (LOI)32.7
Smoke density (Ds max)84.7
ITC / Hazard Level0.06
Railway hazard levelHL1, HL2, HL3
Catalysis typePeroxide
Processing methodExtrusion and moulding
Base colourBlack / Blue-black (RAL 9017 / RAL 5004)
Available coloursBlack (RAL 9017), Blue-black (RAL 5004)
Applications
- Railway applications (seals, profiles, gaskets, thermal protections, insulation panels).
Certifications and technical standards
- EN 45545-2 R22/R23 HL1-HL2-HL3
- RoHS compliant
- REACH compliant
- NF EN 45545-2:2020
- EN ISO 4589-2 (O₂ Index 32.7%)
- EN ISO 5659-2 (Ds max 84.7)
- EN 17084 (ITC PNL 0.06)
Series 13 – Fluorosilicone (FVMQ) with high resistance to oils and solvents
Series 13 is a fluorosilicone blend (FVMQ base) catalysed with peroxide, designed specifically to provide exceptional resistance to mineral oils, fuels and organic solvents. It is processable by extrusion and moulding. Its main feature is its ability to retain its properties in environments where standard silicones (VMQ) would degrade or swell, making it ideal for applications in contact with aggressive fluids.
Fluorosilicone (FVMQ) catalysed with peroxide, processable by extrusion and moulding. It combines good mechanical properties with excellent resistance to oils, fuels and organic solvents. Designed for aggressive environments, with a thermal range from -60 °C to +170 °C (up to +220 °C with thermal additive).
Shore A hardness40 – 70
Temperature range-60 °C / 170 °C
Density (g/cm³)1.40 – 1.46
Tensile strength (MPa)6.0 – 7.0
Elongation at break (%)160 – 400
Tear strength (kN/m)10.0 – 21.0
Catalysis typePeroxide
Processing methodExtrusion and moulding
Base colourNatural / Transparent
Available coloursRAL colours on request
Applications
- Profiles, moulded parts and special components for environments with oils or solvents.
Certifications and technical standards
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/E1/L2)
Series 11 – Peroxide-cure electroconductive silicone
Series 11 is a peroxide-catalysed silicone blend with electroconductive properties. It is processable primarily by moulding (extrusion possible subject to evaluation). Its specific formulation gives it low resistivity, making it ideal for the management of electrical charges, wiring equipment, connectors and electromagnetic shielding (EMI/RFI).
Electrically conductive technical silicone catalysed with peroxide, developed for electrical and connector applications. It offers low resistivity, good thermal stability (-50 °C to +210 °C) and good mechanical strength, available only in black. Processable primarily by moulding and, subject to evaluation, by extrusion.
Shore A hardness50 – 70
Temperature range-50 °C / 210 °C
Density (g/cm³)1.11 – 1.16
Tensile strength (MPa)5.0 – 5.0
Elongation at break (%)100 – 250
Tear strength (kN/m)5.0 – 10.0
Catalysis typePeroxide
Processing methodMoulding (extrusion subject to evaluation)
Base colourBlack
Available coloursBlack only
Applications
- Wiring equipment, connectors, moulded parts and components with electrical conductivity.
Certifications and technical standards
- RoHS compliant
- REACH compliant
- NF ISO 7619-1
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (M2/L2)
Series 15 – Platinum-cure cellular silicone (foam) for extrusion
Series 15 is a cellular (foam) silicone formulation catalysed with platinum, designed specifically for the extrusion process. Its cellular structure allows lightweight, flexible profiles to be produced, ideal for ensuring sealing on irregular surfaces. Platinum curing gives it higher purity and better mechanical properties compared with standard peroxide foams.
HardnessN/A (Cellular material)
Temperature range-60 °C / 200 °C
Density (g/cm³)0.50 – 0.80
Tensile strength (MPa)3.0 – 3.0
Elongation at break (%)600 – 600
Tear strength (kN/m)15.0 – 15.0
Catalysis typePlatinum
Processing methodExtrusion
Base colourVarious RAL colours
Available coloursVarious RAL colours available on request
Applications
- Sealing profiles, gaskets, cellular tubing.
Certifications and technical standards
- FDA 21 CFR §177.2600
- BfR IX and XV
- CE 1935/2004 (depending on formulation)
- RoHS compliant
- REACH compliant
- NF ISO 37
- NF ISO 34-1
- NF ISO 2781
- ISO 3302 (E1/L2)
Series 33 – Platinum-cure cellular silicone (foam) fire-retardant (EN 45545-2)
Series 33 is a cellular (foam) silicone blend catalysed with platinum, designed for processing by extrusion. It is characterised by good sealing performance combined with advanced safety properties: good fire resistance and good self-extinguishing behaviour. It complies with the requirements of EN 45545-2 (R22 and R23, HL1 and HL2 levels), making it ideal for lightweight sealing profiles in transport and demanding applications.
Platinum-catalysed cellular silicone, processable by extrusion. It offers good sealing, excellent fire behaviour and self-extinguishing properties, and a wide range of available colours. Specially developed for railway applications and thermal sealing with compliance to EN 45545-2 R22/R23 (HL1–HL2).
HardnessN/A (Cellular)
Temperature range-60 °C / 200 °C
Density (g/cm³)0.50 – 0.80
Catalysis typePlatinum
Processing methodExtrusion
Base colourWhite / Grey / Black / Oxide red (to order)
Available coloursVarious RAL colours available on request
Applications
- Sealing gaskets, tubing, profiles in cord, square, rectangular or trapezoidal cross-sections with fire resistance and good sealing performance.
Certifications and technical standards
- EN 45545-2:2020 R22/R23 HL1–HL2
- RoHS compliant
- REACH compliant
- ISO 3302 – extruded products E3
- cut lengths L3
